TE Connectivity AMP DUOPLUG MARK II Series Side Edge Connector Female, Board, 4-Contacts, 2.5 mm Pitch, 1 Row, IDC
- RS Stock No.:
- 796-715
- Mfr. Part No.:
- 6-1534796-4
- Brand:
- TE Connectivity
N
Subtotal (1 box of 1000 units)*
$651.24
(exc. GST)
$716.36
(inc. GST)
FREE delivery for orders over $80.00 ex GST
New product - Preorder today
- Shipping from 05 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | $651.24 | $0.651 |
*price indicative
- RS Stock No.:
- 796-715
- Mfr. Part No.:
- 6-1534796-4
- Brand:
- TE Connectivity
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | Edge Connector | |
| Orientation | Side | |
| Current | 2A | |
| Number of Contacts | 4 | |
| Number of Rows | 1 | |
| Connector Gender | Female | |
| Pitch | 2.5mm | |
| Mount Type | Board | |
| Minimum Operating Temperature | -40°C | |
| Termination Type | IDC | |
| Maximum Operating Temperature | 110°C | |
| Voltage | 250V | |
| Housing Material | Nylon | |
| Standards/Approvals | GWEPT 750°C | |
| Series | AMP DUOPLUG MARK II | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type Edge Connector | ||
Orientation Side | ||
Current 2A | ||
Number of Contacts 4 | ||
Number of Rows 1 | ||
Connector Gender Female | ||
Pitch 2.5mm | ||
Mount Type Board | ||
Minimum Operating Temperature -40°C | ||
Termination Type IDC | ||
Maximum Operating Temperature 110°C | ||
Voltage 250V | ||
Housing Material Nylon | ||
Standards/Approvals GWEPT 750°C | ||
Series AMP DUOPLUG MARK II | ||
- COO (Country of Origin):
- AT
The TE Connectivity connector system offers reliable connectivity solutions designed for high productivity and application versatility. This connector is suitable for modern electronic connections and supports a wide range of industrial applications.
Conducts current up to 16 Amperes based on wire size
Features insulation displacement contacts for effortless assembly
Designed for compatibility with various application tooling systems
Utilises a pitch of 5.0 mm for effective modular connections
