DiodesZetex D7V0M1U2S9-7 Uni-Directional TVS Diode, 90 W, 2-Pin SOD-923

This image is representative of the product range

View all TVS Diodes
Bulk discount available

Subtotal (1 pack of 25 units)*

$4.25

(exc. GST)

$4.75

(inc. GST)

Add to Basket
Select or type quantity
In Stock
  • Plus 9,825 unit(s) shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
25 - 475$0.17$4.25
500 - 975$0.166$4.15
1000 - 2475$0.163$4.08
2500 - 4975$0.159$3.98
5000 +$0.156$3.90

*price indicative

Packaging Options:
RS Stock No.:
246-7479
Mfr. Part No.:
D7V0M1U2S9-7
Brand:
DiodesZetex
Find similar products by selecting one or more attributes.
Select all

Brand

DiodesZetex

Product Type

TVS Diode

Direction Type

Uni-Directional

Minimum Breakdown Voltage Vbr

7.5V

Mount Type

Surface

Package Type

SOD-923

Maximum Reverse Stand-off Voltage Vwm

7V

Pin Count

2

Peak Pulse Power Dissipation Pppm

90W

Minimum Operating Temperature

-55°C

ESD Protection

Yes

Clamping Voltage VC

13V

Maximum Peak Pulse Current Ippm

7A

Maximum Operating Temperature

150°C

Length

0.6mm

Height

0.37mm

Standards/Approvals

EC 61000-4-2, ISO, RoHS, UL

Width

0.8 mm

Maximum Reverse Leakage Current

1μA

Automotive Standard

AEC-Q101

The DiodesZetex makes a unidirectional, new generation TVS designed to protect sensitive electronics from the damage due to ESD. The combination of small size and high ESD surge capability makes it ideal for use in portable applications such as cellular phones, digital cameras, and MP3 players.

Provides ESD protection for Air ±30kV, Contact ±30kV 1 Channel of ESD protection Low channel input capacitance
