WickmannSMD Non Resettable Fuse 20A, 250V
- RS Stock No.:
- 174-0699
- Mfr. Part No.:
- 0463020.ER
- Brand:
- Wickmann
2340 In Global stock for delivery within 10 working day(s)
Added
Price (ex. GST) Each (In a Pack of 20)
$6.713
(exc. GST)
$7.384
(inc. GST)
| Units | Per unit | Per Pack* |
| 20 - 620 | $6.713 | $134.26 |
| 640 - 1240 | $6.666 | $133.32 |
| 1260 + | $6.599 | $131.98 |
| *price indicative | ||
- RS Stock No.:
- 174-0699
- Mfr. Part No.:
- 0463020.ER
- Brand:
- Wickmann
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
The Littlefuse Wickman 463 Series, Nano2® is a fast-acting, very high current subminiature surface mount fuse designed for high operating current applications having interrupting ratings of 500A @ 72V DC & 50A @ 100V DC. It offers superior thermal cycling endurance of 500 cycles with its low temperature rise and excellent temperature stability characteristics. It is ideal to be used in datacom and telecom equipment such as high end servers, base stations, power supplies, and blade computing applications.
Surface mount fuse in a small footprint
High current rating 15A-30A
Higher voltage rating up to 100VDC and 250VAC
High melting i2t
Enhanced thermal cycling endurance
Operating temperature range from -55°C to 125°C
RoHS Compliant and Halogen-Free
Recognized to UL/CSA/NMX 248-1 and UL/CSA/NMX 248-14
Conforms to EN/IEC 60127-1 and EN/IEC 60127-7
High current rating 15A-30A
Higher voltage rating up to 100VDC and 250VAC
High melting i2t
Enhanced thermal cycling endurance
Operating temperature range from -55°C to 125°C
RoHS Compliant and Halogen-Free
Recognized to UL/CSA/NMX 248-1 and UL/CSA/NMX 248-14
Conforms to EN/IEC 60127-1 and EN/IEC 60127-7
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
|---|---|
| Current Rating | 20A |
| Voltage Rating | 250V |
| Fuse Speed | FF |
| Body Material | Ceramic |
| Body Length | 10.1mm |
| Body Width | 3.12mm |
| Body Height | 3.12mm |
| Breaking Capacity at Maximum Voltage Rating | 100 A @ 250 V ac, 1000 A @ 32 V dc, 1400 A @ 48 V dc, 2500 A @ 12 V dc, 300 A @ 65 V ac, 50 A @ 100 V dc, 500 A @ 72 V dc, 800 A @ 57 V dc |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +125°C |
| Series | 463 |
| Dimensions | 10.1 x 3.12 x 3.12mm |
| Resistance | 0.002Ω |
| Terminal Material | Silver Plated |
