- RS Stock No.:
- 763-9131
- Mfr. Part No.:
- 33520B
- Brand:
- Keysight Technologies
Stocked by manufacturer – available for delivery 10/07/2024
Added
Price (ex. GST) Each
$5,777.00
(exc. GST)
$6,354.70
(inc. GST)
Units | Per unit |
1 + | $5,777.00 |
Alternative
This product is not currently available. Here is our alternative recommendation.
- RS Stock No.:
- 763-9131
- Mfr. Part No.:
- 33520B
- Brand:
- Keysight Technologies
Legislation and Compliance
- COO (Country of Origin):
- MY
Product Details
Keysight Technologies Function Generator, 2 Channels, 40ps Edge Jitter - 33500B Series - 33520B
Looking for a testing element that generates high-quality signals with minimal noise? Choose this waveform generator from Keysight Technologies. It has a typical crosstalk of less than -85dB to reduce the risk of interference. Thanks to its maximum edge jitter of just 40ps, it allows you to place edges accurately to minimise the risk of timing errors when setting trigger points. Thanks to its built-in Ethernet, LAN, USB and GPIB ports, it connects to other devices with ease.
Features & Benefits
Bandwidth of 30MHz for use in heavy-duty applications
Wide operating temperature range between 0°C and +55°C for use in tough conditions
Low total harmonic distortion of 0.04% ensures good signal integrity
Compact dimensions of 88.3 (height) x 212.8 (width) x 272.3mm (depth) for ease of handling
Wide operating temperature range between 0°C and +55°C for use in tough conditions
Low total harmonic distortion of 0.04% ensures good signal integrity
Compact dimensions of 88.3 (height) x 212.8 (width) x 272.3mm (depth) for ease of handling
Applications
PCB manufacturing industry
Instrumentation and control
Robotics and automation
Instrumentation and control
Robotics and automation
What types of modulation are available on this device?
This device has a wide range of modulation types to choose from, including AM, FM, PM, FSK, BPSK and PWM. This makes it a highly versatile choice.
Specifications
Attribute | Value |
---|---|
Series | 33500B |
Model Number | 33520B |
Digital Frequency | Yes |
Number of Channels | 2 |
Minimum Frequency Range Sinewave | 1µHz |
Maximum Frequency Range Sinewave | 30MHz |
Maximum Frequency Range Square Pulse and Arbitrary Waveform | 30MHz |
Minimum Frequency Range Square Pulse and Arbitrary Waveform | 1 μHz |
Maximum Frequency Range Triangle/Saw | 20kHz |
Minimum Frequency Range Triangle/Saw | 1µHz |
Digital Amplitude and Offset | Yes |
Internal Linear and Log Sweep | Yes |
Variable Sweep | Yes |
Internal and External Amplitude Modulation | Yes |
FM Modulation | Yes |
Time Base Accuracy | ±0.1ppm |
Maximum Operating Temperature | +55°C |
Output Amplitude | 20V Pk-Pk |
Width | 212.8mm |
Length | 272.3mm |
Output Impedance | 50Ω |
Dimensions | 272.3 x 212.8 x 88.3mm |
Interface Type | Ethernet, GPIB, LAN, USB |
Frequency Range Square Pulse and Arbitrary Waveform | 1 μHz → 30 MHz |
Minimum Operating Temperature | 0°C |
Height | 88.3mm |
Input Impedance | 5 kΩ |
Operating Temperature Range | 0 → +55 °C |
Weight | 3.3kg |
