RS PRO 2.54 mm Pitch Vertical 20 Way, Through Hole Turned Pin Closed Frame DIL Socket, 3A
- RS Stock No.:
- 183-1569
- Distrelec Article No.:
- 304-02-803
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 tube of 24 units)*
$25.92
(exc. GST)
$28.56
(inc. GST)
Add 72 units to get free delivery
In Stock
- Plus 960 unit(s) shipping from 23 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tube* |
|---|---|---|
| 24 - 216 | $1.08 | $25.92 |
| 240 - 1176 | $1.05 | $25.20 |
| 1200 + | $0.865 | $20.76 |
*price indicative
- RS Stock No.:
- 183-1569
- Distrelec Article No.:
- 304-02-803
- Brand:
- RS PRO
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Number of Contacts | 20 | |
| Product Type | DIL Socket | |
| Mount Type | Through Hole | |
| Pin Type | Turned | |
| Current | 3A | |
| Pitch | 2.54mm | |
| Row Width | 7.62mm | |
| Voltage | 60 V ac/dc | |
| Frame Type | Closed Frame | |
| Contact Plating | Tin | |
| Orientation | Vertical | |
| Termination Type | Solder | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 105°C | |
| Width | 10.16 mm | |
| Standards/Approvals | No | |
| Length | 25.4mm | |
| Depth | 3mm | |
| Contact Material | Beryllium Copper Alloy, Brass | |
| Housing Material | Thermoplastic | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Number of Contacts 20 | ||
Product Type DIL Socket | ||
Mount Type Through Hole | ||
Pin Type Turned | ||
Current 3A | ||
Pitch 2.54mm | ||
Row Width 7.62mm | ||
Voltage 60 V ac/dc | ||
Frame Type Closed Frame | ||
Contact Plating Tin | ||
Orientation Vertical | ||
Termination Type Solder | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 105°C | ||
Width 10.16 mm | ||
Standards/Approvals No | ||
Length 25.4mm | ||
Depth 3mm | ||
Contact Material Beryllium Copper Alloy, Brass | ||
Housing Material Thermoplastic | ||
- COO (Country of Origin):
- CN
RS PRO Series Machine Pin Sockets offer a full range of exceptional quality, high reliability DIP package Sockets. Our sockets feature solid, precision turned sleeves with a closed bottom design to eliminate flux intrusion and solder wicking during soldering. Stamped spring copper insert provides an excellent connection and allows repeated insertion and withdrawals. Plating options include choice of gold, tin or selective gold plating. Our insulators are molded of high temp thermoplastic.
High Pressure Contacts, Precision Stamped Internal Spring Contacts, Anti-Solder Wicking design, Machine Insertable, Single or Dual Row, Low Profile
