- RS Stock No.:
- 138-5668
- Mfr. Part No.:
- TR610 top 2 24V
- Brand:
- Theben
5 In AU stock for next working day delivery
26 In Global stock for delivery within 10 working day(s)
Added
Price (ex. GST) Each
$406.53
(exc. GST)
$447.18
(inc. GST)
Units | Per unit |
1 + | $406.53 |
- RS Stock No.:
- 138-5668
- Mfr. Part No.:
- TR610 top 2 24V
- Brand:
- Theben
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
Theben Time Switch
The Theben digital time switch is a single channel, DIN rail, single pole double throw (SPDT) device. It is an astronomical time switch with a weekly program and 56 memory locations. It has a supply voltage ranges between 12VAC and 24VAC. The housing material of this switch is highly temperature resistant made with self-extinguishing thermoplastic. This device enables safe transfer via optional Bluetooth low energy OBELISK top3. It is useful for industrial applications.
Features and Benefits
DuoFix spring terminals with wire diameter 0.5mm² and 2.5mm² (with or without wire end sleeve)
Wire or strand button for releasing the plug-in connection
Text-oriented user guidance in display
Pre-set date and time
Fully operable without mains connection
Zero-cross switching for relay-saving switching and high lamp loads
Automatic summer/ winter time changeover
Switching preselection
Permanent switching on/ off
PIN coding
Holiday program
Display back light (can be turned off)
Shortest switching time is 1 minute
The ambient temperature ranges between -30°C and 55°C
Wire or strand button for releasing the plug-in connection
Text-oriented user guidance in display
Pre-set date and time
Fully operable without mains connection
Zero-cross switching for relay-saving switching and high lamp loads
Automatic summer/ winter time changeover
Switching preselection
Permanent switching on/ off
PIN coding
Holiday program
Display back light (can be turned off)
Shortest switching time is 1 minute
The ambient temperature ranges between -30°C and 55°C
Certifications
IP20 rated
EN 60 730-1
VDE
EN 60 730-1
VDE
Specifications
Attribute | Value |
---|---|
Supply Voltage | 12 → 24 V |
Type | Digital |
Number of Channels | 1 |
Units Measured | Days, Hours, Minutes, Seconds |
Segment Length | 1 min |
Contact Configuration | SPDT |
Height | 90.1mm |
Depth | 69.2mm |
Memory Spaces | 56 |
Battery Life | 10yr |
