Sensata / Crydom Solid State Relay, 25 A rms Load, PCB Mount, 660 V ac Load, 32 V Control

RS Stock No.:: 291-2523
Mfr. Part No.:: PFE480D25
Brand:: Sensata / Crydom

Sensata / Crydom Solid State Relay, 25 A rms Load, PCB Mount, 660 V ac Load, 32 V Control

7 In Global stock for delivery within 10 working day(s)

Added

Price (ex. GST) Each

$59.66

(exc. GST)

$65.63

(inc. GST)

Units	Per unit
1 - 9	$59.66
10 - 99	$57.88
100 - 249	$56.11
250 - 499	$54.93
500 +	$53.72

RS Stock No.:: 291-2523
Mfr. Part No.:: PFE480D25
Brand:: Sensata / Crydom

Technical data sheets

Legislation and Compliance

COO (Country of Origin):: MX

Product Details

25 A with Integrated Heat Sink, PF Series

High nominal current in steady state
Low leakage value in off-state
SCR output
AC or DC control

Warning

The reduction in the nominal value will limit the maximum load current for temperatures above 25°C.

Approvals

UL, VDE

Specifications

Attribute	Value
Maximum Load Current	25 A rms
Mounting Type	PCB Mount
Maximum Load Voltage	660 V rms
Minimum Load Voltage	48 V ac
Maximum Control Voltage	32 V
Switching Type	Zero Cross
Control Voltage Range	15 → 32 V dc
Minimum Load Current	0.06 A
Output Device	SCR
Load Voltage Range	48 → 660V ac
Dimensions	43.1 x 22.8 x 34.3mm
Length	43.1mm
Operating Temperature Range	-30 → +80°C
Maximum Operating Temperature	+80°C
Minimum Operating Temperature	-30°C
Depth	22.8mm
Height	34.3mm
