Vishay 200 V 3 A Rectifier & Schottky Diode Schottky 2-Pin SMP

This image is representative of the product range

View this category
Bulk discount available

Subtotal (1 reel of 3000 units)*

$669.00

(exc. GST)

$735.00

(inc. GST)

Add to Basket
Select or type quantity
Being discontinued
  • Final 9,000 unit(s), ready to ship from another location
Units
Per unit
Per Reel*
3000 - 12000$0.223$669.00
15000 +$0.201$603.00

*price indicative

RS Stock No.:
231-5414
Mfr. Part No.:
V3P22HM3/H
Brand:
Vishay
Find similar products by selecting one or more attributes.
Select all

Brand

Vishay

Mount Type

Surface

Product Type

Rectifier & Schottky Diode

Package Type

SMP

Maximum Continuous Forward Current If

3A

Peak Reverse Repetitive Voltage Vrrm

200V

Diode Configuration

Single

Series

V3

Rectifier Type

Schottky

Pin Count

2

Peak Reverse Current Ir

3mA

Maximum Forward Voltage Vf

0.94V

Minimum Operating Temperature

-40°C

Peak Non-Repetitive Forward Surge Current Ifsm

60A

Maximum Operating Temperature

175°C

Width

2.18 mm

Length

4mm

Height

1.15mm

Standards/Approvals

No

Automotive Standard

AEC-Q101

The Vishay surface-mount TMBS (Trench MOS Barrier Schottky) rectifier used in low voltage , high frequency inverters, freewheeling, DC/DC converters, and polarity protection applications.

Low profile package

Trench MOS Schottky technology

Low power losses, high efficiency

Low forward voltage drop
