MPN

OEP Through Hole Pulse Transformer 1:1 Turns Ratio, 2.5 mH Prim. Inductance

Bulk discount available

Subtotal (1 unit)*

$14.42

(exc. GST)

$15.86

(inc. GST)

Orders below $60.00 (exc. GST) cost $12.95.

Temporarily out of stock

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

*price indicative

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	OEP
	Primary Inductance	2.5mH
	Product Type	Pulse Transformer
	Turns Ratio	1:1
	Mount Type	Through Hole
	Leakage Inductance	0.5μH
	Minimum Operating Temperature	0°C
	Maximum Operating Temperature	70°C
	Standards/Approvals	No
	Series	LAD4613
	Length	10.16mm
	Depth	6.35mm
	Width	8.89 mm
	Maximum Operating Frequency	24.6MHz
	Minimum Operating Frequency	0.1MHz
	Isolation Voltage	2kVrms

	Select all
	Brand OEP
	Primary Inductance 2.5mH
	Product Type Pulse Transformer
	Turns Ratio 1:1
	Mount Type Through Hole
	Leakage Inductance 0.5μH
	Minimum Operating Temperature 0°C
	Maximum Operating Temperature 70°C
	Standards/Approvals No
	Series LAD4613
	Length 10.16mm
	Depth 6.35mm
	Width 8.89 mm
	Maximum Operating Frequency 24.6MHz
	Minimum Operating Frequency 0.1MHz
	Isolation Voltage 2kVrms

Transformer for digital audio data transmission

High operating transmission rates

Controlled rise time of 25 nsec maximum

High isolation voltage

SMT and through hole option
