Bourdon NPT 1/2 Analogue Pressure Gauge 40bar Bottom Entry, MEX5-D61.B27, 0bar min.
- RS Stock No.:
- 253-0517
- Mfr. Part No.:
- MEX5-D61.B27
- Brand:
- Bourdon
On back order for despatch 27/08/2024, delivery within 10 working days from despatch date.
Price (ex. GST) Each
$325.67
(exc. GST)
$358.24
(inc. GST)
Units | Per unit |
|---|---|
| 1 + | $325.67 |
- RS Stock No.:
- 253-0517
- Mfr. Part No.:
- MEX5-D61.B27
- Brand:
- Bourdon
Technical data sheets
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- FR
Product Details
The Bourdon MEX5 is stainless steel pressure gauge has nominal size of Ø 100 with 1/2 NPT connection and protected with IP65 rating.
Class 1 according to EN 837-1
Wetted parts Stainless steel (MEX) or Monel (MEM)
Lloyds Register Approval
Option liquid-filled for applications with pulsations or vibrations
Option case material 1.4404 (316L) for aggressive atmosphere
Wetted parts Stainless steel (MEX) or Monel (MEM)
Lloyds Register Approval
Option liquid-filled for applications with pulsations or vibrations
Option case material 1.4404 (316L) for aggressive atmosphere
Specifications
Attribute | Value |
|---|---|
| Maximum Pressure Measurement | 40bar |
| Minimum Pressure Measurement | 0bar |
| Mounting Type | Bottom Entry |
| Display Type | Analogue |
| Connection Size | NPT 1/2 |
| Gauge Outside Diameter | 100mm |
