Infineon BTN70301EPAXUMA1, Brushed DC Motor Motor Driver IC 17 A 14-Pin, TSDSO
- RS Stock No.:
- 228-6519
- Mfr. Part No.:
- BTN70301EPAXUMA1
- Brand:
- Infineon
This image is representative of the product range
Bulk discount available
View bulk pricing optionsSubtotal (1 pack of 5 units)*
$19.55
(exc. GST)
$21.50
(inc. GST)
FREE delivery for orders over $80.00 ex GST
In Stock
- 390 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 5 | $3.91 | $19.55 |
| 10 - 95 | $3.792 | $18.96 |
| 100 - 245 | $3.68 | $18.40 |
| 250 - 495 | $3.568 | $17.84 |
| 500 + | $3.46 | $17.30 |
*price indicative
- RS Stock No.:
- 228-6519
- Mfr. Part No.:
- BTN70301EPAXUMA1
- Brand:
- Infineon
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Motor Type | Brushed DC Motor | |
| Product Type | Motor Driver IC | |
| Configuration | H Bridge | |
| Maximum IGBT Collector Current | 17A | |
| Mount Type | Surface | |
| Package Type | TSDSO | |
| Pin Count | 14 | |
| Output Current | 7A | |
| Minimum Supply Voltage | 6V | |
| Maximum Supply Voltage | 18V | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 150°C | |
| Series | BTN7030 | |
| Width | 3.9mm | |
| Standards/Approvals | No | |
| Length | 4mm | |
| Height | 1.15mm | |
| Supply Current | 20μA | |
| Automotive Standard | AEC | |
| Select all | ||
|---|---|---|
Brand Infineon | ||
Motor Type Brushed DC Motor | ||
Product Type Motor Driver IC | ||
Configuration H Bridge | ||
Maximum IGBT Collector Current 17A | ||
Mount Type Surface | ||
Package Type TSDSO | ||
Pin Count 14 | ||
Output Current 7A | ||
Minimum Supply Voltage 6V | ||
Maximum Supply Voltage 18V | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 150°C | ||
Series BTN7030 | ||
Width 3.9mm | ||
Standards/Approvals No | ||
Length 4mm | ||
Height 1.15mm | ||
Supply Current 20μA | ||
Automotive Standard AEC | ||
Infineon BTN7030 Series Motor Driver IC, 6V Minimum Supply Voltage, 7A Output Current - BTN70301EPAXUMA1
This motor driver IC is a surface-mount H-bridge controller designed to drive brushed DC motors within automotive contexts. It operates from a low 6V up to 18V supply and delivers continuous output current suitable for moderate-power motors. The device is supplied in a Compact TSDSO 14-pin package and has a minimal quiescent supply current, making it suitable for applications where standby current matters.
Features and Benefits:
• 7A output current providing sustained motor drive capability
• 6V to 18V supply range enabling flexible vehicle and battery use
• Low supply current 20μA reducing standby power consumption
• 17A IGBT collector compatibility supporting robust switching stages
• High temperature tolerance to 150°C enabling harsh-environment operation
• 6V to 18V supply range enabling flexible vehicle and battery use
• Low supply current 20μA reducing standby power consumption
• 17A IGBT collector compatibility supporting robust switching stages
• High temperature tolerance to 150°C enabling harsh-environment operation
Applications
• Suitable for automotive actuator control in body systems
• Ideal for brushed DC window and mirror drive mechanisms
• Used with power stages incorporating IGBT transistors
• Can be used for compact, surface-mounted motor controller modules
• Suitable for vehicle components requiring AEC-class performance
• Ideal for brushed DC window and mirror drive mechanisms
• Used with power stages incorporating IGBT transistors
• Can be used for compact, surface-mounted motor controller modules
• Suitable for vehicle components requiring AEC-class performance
What packaging and mounting style does it use?
It is supplied in a TSDSO 14-pin package and intended for surface mounting.
What temperature range can it withstand during operation?
The device operates across a range down to -40°C and up to 150°C.
How does it suit automotive design requirements?
It conforms to automotive AEC standards and supports H-bridge motor control for vehicle systems.
What configuration does the output stage provide?
The internal arrangement is an H-bridge suitable for bidirectional control of brushed DC motors.
