Maxim Integrated 6 V -0.5 V Laser Driver 24-Pin QFN
- RS Stock No.:
- 191-4278
- Mfr. Part No.:
- MAX3738ETG+
- Brand:
- Maxim Integrated
This image is representative of the product range
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 191-4278
- Mfr. Part No.:
- MAX3738ETG+
- Brand:
- Maxim Integrated
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Maxim Integrated | |
| Product Type | Laser Driver | |
| Laser Type Driven | SFP, SFF | |
| Maximum Output Current | 100mA | |
| Package Type | QFN | |
| Number of Pins | 24 | |
| Length | 4.1mm | |
| Maximum Supply Voltage | 6V | |
| Minimum Supply Voltage | -0.5V | |
| Width | 4.1 mm | |
| Standards/Approvals | No | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Maxim Integrated | ||
Product Type Laser Driver | ||
Laser Type Driven SFP, SFF | ||
Maximum Output Current 100mA | ||
Package Type QFN | ||
Number of Pins 24 | ||
Length 4.1mm | ||
Maximum Supply Voltage 6V | ||
Minimum Supply Voltage -0.5V | ||
Width 4.1 mm | ||
Standards/Approvals No | ||
Automotive Standard No | ||
Single +3.3V Power Supply
47mA Power-Supply Current
85mA Modulation Current
100mA Bias Current
Automatic Power Control (APC)
Modulation Compensation
On-Chip Temperature Compensation
Self-Biased Inputs for AC-Coupling
Ground-Referenced Current Monitors
Laser Shutdown and Alarm Outputs
Enable Control and Laser Safety Feature
Applications/Uses
1Gbps/2Gbps/4Gbps Fibre Channel SFF/SFP and GBIC Transceivers
Gigabit Ethernet SFF/SFP and GBIC Transceivers
Multirate OC-24 to OC-48 FEC Transceivers
