TDK-Lambda DRL-30 Switched Mode DIN Rail Power Supply, 85 → 264V ac ac Input, 12V dc dc Output, 2.1A Output, 30W
- RS Stock No.:
- 137-0852
- Mfr. Part No.:
- DRL30-12-1
- Brand:
- TDK-Lambda
17 In Global stock for delivery within 10 working day(s)
Added
Price (ex. GST) Each
$66.80
(exc. GST)
$73.48
(inc. GST)
Units | Per unit |
1 + | $66.80 |
- RS Stock No.:
- 137-0852
- Mfr. Part No.:
- DRL30-12-1
- Brand:
- TDK-Lambda
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
DRL Series DIN Rail Power Supplies
The low profile DRL series DIN Rail power supply provides a reliable solution for many industrial applications and building automation. With double insulation and safety Class II input, connection to earth is not required. The NEC Class 2 compliant output, in accordance with UL 1310, allows operation where output currents are to be limited under fault conditions. Available in four power ranges, the DRL series provide a choice of 12 and 24 output voltages.
Features and Benefits
• Protection Class II
• No load power < 0.3 W to 0.5 W
• Universal AC input 85 V ac to 264 V ac
• 12 V and 24 V dc
• Operating temperature -20°C to +71°C
Product Application Information
• Building control
• Security and surveillance
• Climate controls
• Smart home
• Renewable energy
Specifications
Attribute | Value |
---|---|
Type | Switched Mode |
Output Voltage | 12V dc |
Output Current | 2.1A |
AC or DC Input Voltage | ac |
AC or DC Output Voltage | dc |
Input Voltage | 85 → 264V ac |
Power Rating | 30W |
Electrical Phase | 1 |
Number of Outputs | 1 |
Height | 91mm |
Width | 36mm |
Depth | 55.6mm |
Series | DRL-30 |
Load Regulation | 120mV |
Minimum Temperature | -20°C |
Ripple And Noise | 120mV |
Maximum Temperature | +71°C |
Standards Met | IEC 60068-2-27, IEC 60068-2-6, UL 1310, UL 508, UL 60950-1 |
Output Voltage Adjustment Range | 12 → 15V |
Mounting Type | DIN Rail Mount |
Special Features | High In-Service Lifetime, Low No Load Consumption |
