Eaton Blue Round Push Button Lens for Use with M22S-DGL-X, M22(S)-DRL-X, M30C-FDRL-X, M30C-FDL-X, M22(S)-DL-X
- RS Stock No.:
- 229-9457
- Mfr. Part No.:
- 218304 M22-XDL-B-X6
- Brand:
- Eaton
Subtotal (1 pack of 10 units)*
$67.40
(exc. GST)
$74.10
(inc. GST)
FREE delivery for orders over $80.00 ex GST
In Stock
- Plus 70 unit(s) shipping from 15 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 10 + | $6.74 | $67.40 |
*price indicative
- RS Stock No.:
- 229-9457
- Mfr. Part No.:
- 218304 M22-XDL-B-X6
- Brand:
- Eaton
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Push Button Lens | |
| For Use With | M22S-DGL-X, M22(S)-DRL-X, M30C-FDRL-X, M30C-FDL-X, M22(S)-DL-X | |
| Lens Colour | Blue | |
| Lens Shape | Round | |
| Height | 2.5mm | |
| Diameter | 22.2mm | |
| Width | 0mm | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Push Button Lens | ||
For Use With M22S-DGL-X, M22(S)-DRL-X, M30C-FDRL-X, M30C-FDL-X, M22(S)-DL-X | ||
Lens Colour Blue | ||
Lens Shape Round | ||
Height 2.5mm | ||
Diameter 22.2mm | ||
Width 0mm | ||
Standards/Approvals No | ||
Eaton Push Button Lens, 22.2mm Diameter, Blue - 218304 M22-XDL-B-X6
This push-button lens is a coloured replacement element designed for panel-mounted control assemblies in industrial environments. It provides a coloured indicator surface compatible with a range of circular control heads and is intended for use where a clear, Durable Visual actuator lens is required.
Features and Benefits:
• 22.2mm diameter ensures correct panel cutout alignment and fit • Round profile delivers uniform illumination and viewing angle • 3mm height gives a low-profile, flush-mounted appearance • Blue optical element offers clear state indication for operators • Compatible with several control head types for straightforward replacement
Applications
• Suitable for refurbishment of M22S-DGL-X front operators • Ideal for replacing lenses on M22(S)-DRL-X indicator assemblies • Used with M30C-FDRL-X and M30C-FDL-X style control heads • Can be used for maintenance of M22(S)-DL-X panels requiring blue indicators
What panel hole size does it match?
The lens is intended for a 22.2mm circular panel cutout to ensure secure seating.
How does the lens affect Visual signalling?
The coloured element provides a consistent, visible surface for illumination or colour-coded status without altering light-source characteristics.
Will it fit differing control head depths?
The low 3mm profile accommodates a range of front-panel depths while maintaining a flush finish.
Is this lens suitable for stock spare parts?
It can be held as a spare element for targeted replacements on compatible operator types used in electrical and automation equipment.
Note
Eaton formerly known as Moeller
