Isocom, ISP814X AC Input Transistor Output Optocoupler, Through Hole, 4-Pin PDIP
- RS Stock No.:
- 453-0971
- Mfr. Part No.:
- ISP814X
- Brand:
- Isocom
View all Optocouplers
550 In Global stock for delivery within 10 working day(s)
Price (ex. GST) Each (In a Pack of 10)
$0.607
(exc. GST)
$0.668
(inc. GST)
| units | Per unit | Per Pack* |
| 10 - 40 | $0.607 | $6.07 |
| 50 - 190 | $0.596 | $5.96 |
| 200 - 490 | $0.577 | $5.77 |
| 500 - 990 | $0.563 | $5.63 |
| 1000 + | $0.551 | $5.51 |
| *price indicative | ||
- RS Stock No.:
- 453-0971
- Mfr. Part No.:
- ISP814X
- Brand:
- Isocom
Technical data sheets
Legislation and Compliance
Product Details
Optocoupler, AC Input, Transistor Output, Isocom Components
Optocouplers, Isocom Components
Specifications
Attribute | Value |
|---|---|
| Mounting Type | Through Hole |
| Output Device | Transistor |
| Maximum Forward Voltage | 1.4V |
| Number of Channels | 1 |
| Number of Pins | 4 |
| Package Type | PDIP |
| Input Current Type | AC |
| Typical Rise Time | 4µs |
| Maximum Input Current | 50 mA |
| Isolation Voltage | 5.3 kVrms |
| Maximum Current Transfer Ratio | 300% |
| Minimum Current Transfer Ratio | 20 % |
| Typical Fall Time | 3µs |
