Omron XM3F 15 Way Through Hole D-sub Connector Socket
- RS Stock No.:
- 201-8043
- Mfr. Part No.:
- XM3F-1520
- Brand:
- Omron
10 In Global stock for delivery within 5 working day(s)
Added
Price (ex. GST) Each
$18.10
(exc. GST)
$19.91
(inc. GST)
| Units | Per unit |
| 1 - 4 | $18.10 |
| 5 - 9 | $17.57 |
| 10 - 19 | $17.04 |
| 20 - 49 | $16.68 |
| 50 + | $16.32 |
- RS Stock No.:
- 201-8043
- Mfr. Part No.:
- XM3F-1520
- Brand:
- Omron
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
The Omron durable D-sub miniature connector with a robust steel shell, stamped and formed contact and solder termination for the easy connection of wire. These D-sub connector are ideal for use for making I/O (input/output) interconnection in a wide range of industrial and commercial application. In this socket with straight DIP terminal there is no anchor or grounding fixture and its shell size is A
Its operating temperature is -55 to 105 °C
Gold plated stamped and formed contact
Gold plated stamped and formed contact
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 15 |
| Gender | Female |
| Body Orientation | Straight |
| Mounting Type | Through Hole |
| D Connector Type | Standard D-Sub |
| Termination Method | Solder |
| D-Sub Shell Size | A |
| Series | XM3F |
