onsemi MC74HC573ADWR2G, Voltage Level Shifter 1, 20-Pin SOIC
- RS Stock No.:
- 186-8533
- Mfr. Part No.:
- MC74HC573ADWR2G
- Brand:
- onsemi
1300 In Global stock for delivery within 10 working day(s)
Added
Price (ex. GST) Each (In a Pack of 25)
$1.106
(exc. GST)
$1.217
(inc. GST)
| Units | Per unit | Per Pack* |
| 25 - 225 | $1.106 | $27.65 |
| 250 - 475 | $1.096 | $27.40 |
| 500 + | $1.061 | $26.525 |
| *price indicative | ||
- RS Stock No.:
- 186-8533
- Mfr. Part No.:
- MC74HC573ADWR2G
- Brand:
- onsemi
Technical data sheets
Legislation and Compliance
Product Details
High-Performance Silicon-Gate CMOS The MC74HC573A is identical in pinout to the LS573. The devices are compatible with standard CMOS outputs, with pullup resistors, they are compatible with LSTTL outputs. These latches appear transparent to data (i.e., the outputs change asynchronously) when Latch Enable is high. When Latch Enable goes low, data meeting the setup and hold time becomes latched. The HC573A is identical in function to the HCT373A but has the data inputs on the opposite side of the package from the outputs to facilitate PC board layout.
Output Drive Capability: 15 LSTTL Loads
Outputs Directly Interface to CMOS, NMOS and TTL
Operating Voltage Range: 2.0 to 6.0 V
Low Input Current: 1.0 mA
Chip Complexity: 218 FETs or 54.5 Equivalent Gates
Outputs Directly Interface to CMOS, NMOS and TTL
Operating Voltage Range: 2.0 to 6.0 V
Low Input Current: 1.0 mA
Chip Complexity: 218 FETs or 54.5 Equivalent Gates
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
|---|---|
| Logic Family | HC |
| Mounting Type | Surface Mount |
| Number of Elements per Chip | 1 |
| Package Type | SOIC |
| Pin Count | 20 |
| Output Type | 3 State |
| Dimensions | 12.95 x 7.6 x 2.4mm |
| Maximum Low Level Output Current | 7.8mA |
| Maximum High Level Output Current | 7.8mA |
| Propagation Delay Test Condition | 50pF |
| Maximum Propagation Delay Time @ Maximum CL | 225 ns @ 50 pF |
| Maximum Operating Supply Voltage | 2 to 6 V |
| Maximum Operating Temperature | +125 °C |
| Minimum Operating Supply Voltage | 2 V |
| Automotive Standard | AEC-Q100 |
| Minimum Operating Temperature | -55 °C |
