MEAN WELL Switching Power Supply, MPM-05-24, 24V dc, 230mA, 5.5W, 1 Output, 80 → 264V ac Input Voltage
- RS Stock No.:
- 174-8052
- Mfr. Part No.:
- MPM-05-24
- Brand:
- MEAN WELL
1 In Global stock for delivery within 10 working day(s)
Added
Price (ex. GST) Each
$21.01
(exc. GST)
$23.11
(inc. GST)
Units | Per unit |
1 - 9 | $21.01 |
10 - 49 | $20.80 |
50 + | $20.41 |
- RS Stock No.:
- 174-8052
- Mfr. Part No.:
- MPM-05-24
- Brand:
- MEAN WELL
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
1.8"x1" compact size
Suitable for BF application with appropriate system consideration
No load power consumption<0.075W
Extremely low leakage current
Wide operating temp. Range -40 ∼ +85℃
EMI class B for class Ⅱ configuration
Protections:
Short circuit / Overload / Over voltage / Over temperature
No minimum load required
Typically lifetime>48K hours
3 years warranty
Suitable for BF application with appropriate system consideration
No load power consumption<0.075W
Extremely low leakage current
Wide operating temp. Range -40 ∼ +85℃
EMI class B for class Ⅱ configuration
Protections:
Short circuit / Overload / Over voltage / Over temperature
No minimum load required
Typically lifetime>48K hours
3 years warranty
AC-DC Single output Medical Encapsulated power supply. Output 24Vdc at 0.23A, PCB through hole, 2xMOPP
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
---|---|
Output Voltage | 24V dc |
Output Current | 230mA |
Power Rating | 5.5W |
Number of Outputs | 1 |
Input Voltage | 80 → 264V ac |
Mounting Type | PCB Mount |
Package Type | Encapsulated |
Length | 45.7mm |
Width | 25.4mm |
Medical Approved | Yes |
Depth | 21.5mm |
Minimum Temperature | -40°C |
Weight | 35g |
Maximum Temperature | +85°C |
