Infineon ICC80QSGXUMA1, PWM Controller
- RS Stock No.:
- 260-1179
- Mfr. Part No.:
- ICC80QSGXUMA1
- Brand:
- Infineon
On back order for despatch 05/11/2024, delivery within 10 working days from despatch date.
Added
Price (ex. GST) Each (On a Reel of 2500)
$0.566
(exc. GST)
$0.623
(inc. GST)
| Units | Per unit | Per Reel* |
| 2500 - 2500 | $0.566 | $1,415.00 |
| 5000 - 5000 | $0.509 | $1,272.50 |
| 7500 + | $0.458 | $1,145.00 |
| *price indicative | ||
- RS Stock No.:
- 260-1179
- Mfr. Part No.:
- ICC80QSGXUMA1
- Brand:
- Infineon
Technical data sheets
Legislation and Compliance
Product Details
The Infineon fly back controller is tailored for battery charger application to meet the required performance. It has Quasi-resonant mode (QRM) operation with continuous conduction mode (CCM)-prevention and valley switching discontinuous conduction mode (DCM) in mid to light load. It is also suited for adapter, printer, PC, TV, monitor, set-top box, audio amplifier applications up to 130 W.
Supports on/off control with external pull-down signal
Soft start to reduce component stress during turn-on
External start-up circuit control signal
Soft start to reduce component stress during turn-on
External start-up circuit control signal
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
|---|---|
| Start-up Supply Current | 30µA |
| Maximum Supply Current | 2 mA |
| Output Voltage | 26 V |
