RS PRO 2 Core Power Cable, 2.5 mm², 100m, Orange Polyolefin Sheath, CR1/C1, 16 A, 300 V, 500 V

RS Stock No.:: 136-8152
Brand:: RS PRO

RS PRO 2 Core Power Cable, 2.5 mm², 100m, Orange Polyolefin Sheath, CR1/C1, 16 A, 300 V, 500 V

1 In Global stock for delivery within 10 working day(s)

Price (ex. GST) 1 Reel of 100 Metre(s)

$1,005.73

(exc. GST)

$1,106.30

(inc. GST)

Reel(s)	Per Reel	Per Metre*
1 - 4	$1,005.73	$10.057
5 +	$827.72	$8.277

*price indicative

RS Stock No.:: 136-8152
Brand:: RS PRO

Datasheet
Cable Selection Guide

Attribute	Value
Cross Sectional Area	2.5 mm²
Number of Cores	2
Sheath Colour	Orange
Length	100m
Armoured	No
Cable Type	CR1/C1
Current Rating	16 A
Sheath Material	Polyolefin
Outer Diameter	9.2mm
Voltage Rating	300 V, 500 V
Conductor Strand Type	Solid
Series	CRCA
Number of Strands	1
American Wire Gauge	13 AWG
Cable Shape	Multi-Conductor
Insulation Material	Polyolefin
Standards Met	NF C 32-013 Class 1 or IEC 60228 Class 2, NF C 32-070 Fire Retardant, NF C 32-310, NF C 32-310 Fire Resistant, NF EN 50267 2-1 No toxic no Corrosives Smoke, NF EN 50267-2-2 Halogen Free, NF EN 50268-2 Low smoke, NFC32-070 and Conform with IEC60332-1
Maximum Operating Temperature	+90°C
Minimum Operating Temperature	-20°C
Fire Behaviour	Fire Resistant
Conductor Material	Copper

RS PRO 2 Core Power Cable, 2.5 mm², 100m, Orange Polyolefin Sheath, CR1/C1, 16 A, 300 V, 500 V

RS Pro CR1/C1 Fire Resistant Cable

Featues and Benefits

Standards
