Teledyne LeCroy T3DSO1000A Series, 200 MHz Bench Oscilloscope 2-Channel

View all Oscilloscopes

Subtotal (1 unit)*

$2,466.97

(exc. GST)

$2,713.67

(inc. GST)

Add to Basket
Select or type quantity
In Stock
  • 2 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +$2,466.97

*price indicative

RS Stock No.:
215-1103
Distrelec Article No.:
301-35-307
Mfr. Part No.:
T3DSO1202A
Brand:
Teledyne LeCroy
Find similar products by selecting one or more attributes.
Select all

Brand

Teledyne LeCroy

Product Type

Oscilloscope

Bandwidth

200MHz

Number of Channels

2

Oscilloscope Type

Bench

Interface Type

CAN, I2C, LIN, SPI, UART/RS232

Series

T3DSO1000A

Standards/Approvals

No

Width

132.6 mm

Height

151mm

Maximum Time Base

100s/div

Maximum Vertical Sensitivity

10V/div

Minimum Time Base

500ps/div

Power Source

Mains

Vertical Resolution

8 bit

COO (Country of Origin):
CN
The Teledyne LeCroy Test Tools new T3DSO1000A Oscilloscopes feature two channel models. The two channel model is available in 200 MHz or 350 MHz bandwidths, The A series has a single 2 GSa/s ADC. When both channels are enabled, each channel has a maximum sample rate of 1 GSa/s. When a single channel is active, that channel has sample rate of 2 GSa/s. Maximum waveform capture rate up to 1 GSa/s, Record length up to 14 Mpts/CH. For ease-of-use, the most commonly used functions can be accessed with its user-friendly front panel design.

Advanced Trigger – Edge, Slope, Pulse Width, Window, Runt, Interval, Time Out (Dropout), Pattern

Waveform Sequence Recorder – record and playback up to 80,000 waveforms. Allows users to replay the changes which have occurred in their waveform history.

Connectivity – USB for mass storage, printing and PC control, plus LAN for fast data transfer
