Dold Current Monitoring Relay, 1 Phase, DPDT, DIN Rail

RS Stock No.:: 240-9320
Mfr. Part No.:: BA9053/410 AC1A/5A/10A AC230V 0-20S
Brand:: Dold

Dold Current Monitoring Relay, 1 Phase, DPDT, DIN Rail

2 In Global stock for delivery within 10 working day(s)

Added

Price (ex. GST) Each

$586.73

(exc. GST)

$645.40

(inc. GST)

Units	Per unit
1 +	$586.73

RS Stock No.:: 240-9320
Mfr. Part No.:: BA9053/410 AC1A/5A/10A AC230V 0-20S
Brand:: Dold

Technical data sheets

Datasheet - BA9053

Legislation and Compliance

COO (Country of Origin):: DE

Product Details

Current monitoring relay, BA9053 / 410

For DC and AC
Three measurement ranges: 0.1 → 1 A; 0.5 → 5 A; 1 → 10 A
Working current principle
High overload capacity
Permissible measurement frequency up to 400 Hz
1 changeover
LED indicates operational readiness and contact position

The BA9053 / 410 current relay is a static measurement relay with isolated measurement and auxiliary circuits. It is suitable for monitoring direct and alternating currents (compensated to effective value). The response value is adjusted, and the fallback value is adjusted by hysteresis. The device operates as an overcurrent relay with adjustable time delay, but can also be used as an undercurrent relay (as per IEC 255, VDE 0345).

Specifications

Attribute	Value
Monitoring Application	Current
Electrical Phase	1
Contact Configuration	DPDT
Mounting Type	DIN Rail
Minimum Current Sensed	0.1A
Maximum Current Sensed	10A
Time Delay	0 → 20s
Series	BA 9053
Height	75mm
Dimensions	120 x 45 x 75mm
Length	120mm
Minimum Operating Temperature	-20°C
Width	45mm
Maximum Operating Temperature	+50°C
Operating Temperature Range	+50°C
Current Range	0.1 → 1 A, 0.5 → 5 A, 1 → 10A
