- RS Stock No.:
- 133-0947
- Mfr. Part No.:
- ATTINY13-20PU
- Brand:
- Microchip
120 In Global stock for delivery within 10 working day(s)
Added
Price (ex. GST) Each (In a Pack of 5)
$2.754
(exc. GST)
$3.029
(inc. GST)
Units | Per unit | Per Pack* |
5 - 20 | $2.754 | $13.77 |
25 - 95 | $2.672 | $13.36 |
100 + | $2.592 | $12.96 |
*price indicative |
- RS Stock No.:
- 133-0947
- Mfr. Part No.:
- ATTINY13-20PU
- Brand:
- Microchip
Technical data sheets
Legislation and Compliance
Product Details
8-Bit tinyAVR® Microcontrollers
Atmel's tinyAVR® devices are optimized for applications that require performance, power efficiency, and ease-of-use in a small package.
Small for applications where size is critical
Capacitive Touch
Fast and code efficient
High integration
1.8V to 5.5V operation (ATtiny43U)
Capacitive Touch
Fast and code efficient
High integration
1.8V to 5.5V operation (ATtiny43U)
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
---|---|
Family Name | ATtiny13 |
Package Type | PDIP |
Mounting Type | Through Hole |
Pin Count | 8 |
Device Core | AVR |
Data Bus Width | 8bit |
Program Memory Size | 1 kB |
Maximum Frequency | 20MHz |
RAM Size | 64 B |
USB Channels | 0 |
Number of PWM Units | 1 |
Number of SPI Channels | 1 |
Number of UART Channels | 0 |
Number of USART Channels | 0 |
Number of I2C Channels | 0 |
Number of CAN Channels | 0 |
Typical Operating Supply Voltage | 2.7 → 5.5 V |
Number of PCI Channels | 0 |
Height | 4.826mm |
Number of LIN Channels | 0 |
Width | 7.112mm |
Dimensions | 10.16 x 7.112 x 4.826mm |
Pulse Width Modulation | 1 (2 Channel) |
ADCs | 4 x 10 bit |
Length | 10.16mm |
Program Memory Type | Flash |
Number of ADC Units | 1 |
Instruction Set Architecture | RISC |
Minimum Operating Temperature | -40 °C |
Maximum Number of Ethernet Channels | 0 |
Number of Ethernet Channels | 0 |
Maximum Operating Temperature | +85 °C |
