Tesa 50577 Conductive Aluminium Tape, 50mm x 25 m 160 °C Max, Black
- RS Stock No.:
- 763-9009
- Distrelec Article No.:
- 110-52-073
- Mfr. Part No.:
- 50577-00000-01
- Brand:
- Tesa
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
$102.37
(exc. GST)
$112.61
(inc. GST)
FREE delivery for orders over $80.00 ex GST
In Stock
- 42 unit(s) ready to ship from another location
- Plus 16 unit(s) shipping from 17 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 5 | $102.37 |
| 6 - 29 | $100.86 |
| 30 + | $82.99 |
*price indicative
- RS Stock No.:
- 763-9009
- Distrelec Article No.:
- 110-52-073
- Mfr. Part No.:
- 50577-00000-01
- Brand:
- Tesa
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Tesa | |
| Backing Material | Aluminium Foil | |
| Product Type | Aluminium Tape | |
| Width | 50mm | |
| Thickness | 90μm | |
| Length | 25m | |
| Conductivity | Conductive | |
| Colour | Black | |
| Adhesion Strength | 5N/cm | |
| Adhesive Material | Acrylic | |
| Tensile Strength | 40N/cm | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 160°C | |
| Complies with EN Legislation | No | |
| Standards/Approvals | No | |
| Model Number | 50577 | |
| Select all | ||
|---|---|---|
Brand Tesa | ||
Backing Material Aluminium Foil | ||
Product Type Aluminium Tape | ||
Width 50mm | ||
Thickness 90μm | ||
Length 25m | ||
Conductivity Conductive | ||
Colour Black | ||
Adhesion Strength 5N/cm | ||
Adhesive Material Acrylic | ||
Tensile Strength 40N/cm | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 160°C | ||
Complies with EN Legislation No | ||
Standards/Approvals No | ||
Model Number 50577 | ||
- COO (Country of Origin):
- DE
TESA Aluminium Tape, 50mm Width, 25m Length - 50577-00000-01
This aluminium tape is a conductive black foil adhesive solution designed for thermal and electrical applications. It combines a metal backing with an acrylic adhesive to deliver consistent conductivity and withstands a wide ambient range for use where both mechanical fastening and electrical continuity are required.
Features and Benefits:
• Conductive backing provides effective EMI/RFI shielding
• Acrylic adhesive offers steady bond with 5N/cm adhesion
• Tensile strength of 40N/cm resists mechanical strain
• Operates between -40°C and 160°C for varied conditions
• 0.09mm thickness allows conformable surface contact
• Acrylic adhesive offers steady bond with 5N/cm adhesion
• Tensile strength of 40N/cm resists mechanical strain
• Operates between -40°C and 160°C for varied conditions
• 0.09mm thickness allows conformable surface contact
Applications
• Suitable for HVAC and ducting sealing and repair
• Ideal for conductive shielding in electrical assemblies
• Used with insulation wraps for high-temperature joints
• Can be used for metal surface repairs and seams
• Suitable for industrial masking and surface protection
• Ideal for conductive shielding in electrical assemblies
• Used with insulation wraps for high-temperature joints
• Can be used for metal surface repairs and seams
• Suitable for industrial masking and surface protection
What is the tape’s backing material composition?
The backing is aluminium foil providing a conductive metal layer.
How does the adhesive perform on metal substrates?
The acrylic adhesive delivers an adhesion strength of 5N/cm for secure metal bonding.
What mechanical resistance does it offer against tension?
The tape has a tensile strength rating of 40N/cm to withstand pull forces.
What temperature extremes can it tolerate during operation?
It is rated for use from -40°C up to a maximum of 160°C.
What are the roll dimensions and Visual finish?
The roll is 50mm wide and 25m long with a black conductive finish.
