Honeywell GL Series Roller Lever Limit Switch, 1 NO/1 NC, IP67, Die Cast Zinc Housing, 240V ac, 6A

RS Stock No.:: 217-7136
Distrelec Article No.:: 136-30-797
Mfr. Part No.:: GLCC01D
Brand:: Honeywell

Honeywell GL Series Roller Lever Limit Switch, 1 NO/1 NC, IP67, Die Cast Zinc Housing, 240V ac, 6A

Subtotal (1 unit)*

$218.00

(exc. GST)

$239.80

(inc. GST)

Stock information currently inaccessible - Please check back later

Units	Per unit
1 +	$218.00

*price indicative

RS Stock No.:: 217-7136
Distrelec Article No.:: 136-30-797
Mfr. Part No.:: GLCC01D
Brand:: Honeywell

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Honeywell
	Actuator Type	Roller Lever
	Product Type	Limit Switch
	Contact Configuration	1 NO/1 NC
	IP Rating	IP67
	Housing Material	Die Cast Zinc
	Contact Type	Snap Action
	Terminal Type	Screw
	Switching Current	6A
	Series	GL
	Minimum Operating Temperature	-40°C
	Switching DC Voltage	250V dc
	Switching AC Voltage	240V ac
	Maximum Operating Temperature	85°C
	Standards/Approvals	CCC1, CCC1 GB14048.5, CE, Conforms to CE, CSA, IEC/EN 60947-5-1, CSA C22.2 14, EN45545-2 (GLC/GLE), UL, UL 508, EN50047
	Hazardous Area Certification	NO
	Mechanical Life	10000000Cycles
	Operating Force	10N

	Select all
	Brand Honeywell
	Actuator Type Roller Lever
	Product Type Limit Switch
	Contact Configuration 1 NO/1 NC
	IP Rating IP67
	Housing Material Die Cast Zinc
	Contact Type Snap Action
	Terminal Type Screw
	Switching Current 6A
	Series GL
	Minimum Operating Temperature -40°C
	Switching DC Voltage 250V dc
	Switching AC Voltage 240V ac
	Maximum Operating Temperature 85°C
	Standards/Approvals CCC1, CCC1 GB14048.5, CE, Conforms to CE, CSA, IEC/EN 60947-5-1, CSA C22.2 14, EN45545-2 (GLC/GLE), UL, UL 508, EN50047
	Hazardous Area Certification NO
	Mechanical Life 10000000Cycles
	Operating Force 10N

Honeywell Series GL Limit Switch, Top Lever Actuator, IP66 - GLCC01D

This limit switch is a rugged electromechanical device designed to detect and interrupt motion in industrial control systems. It operates via a top-mounted lever actuator to provide positive snap-action switching for machinery and automation. The unit is housed in a Durable plastic enclosure with environmental protection suitable for demanding indoor and outdoor installations.

Features and Benefits:

• Snap-action contacts deliver quick switching and positive state change
• Dual-contact arrangement offers both normally open and normally closed outputs
• Rated for 6A at 240V AC to handle common control circuits
• Can switch up to 250V DC enabling DC control applications
• Wide temperature tolerance supports operation from -40°C to 85°C
• Mechanical endurance specified to 10 million cycles for extended service life

Applications

• Suitable for conveyor end-of-travel detection in factory automation
• Ideal for position sensing on industrial presses and actuators
• Used with safety interlocks on access panels and guards
• Can be used for limit detection in material handling systems

What contact operation does it provide for control wiring?

It provides one normally open and one normally closed contact to allow both make and break signalling within a single device.

How does the actuator type influence mounting options?

The TOP lever actuator permits actuation from above and is compatible with applications where motion engages a vertical or angled lever.

What standards or approvals cover its electrical and safety characteristics?

It meets multiple regional and international standards for low-voltage switching equipment and railway fire safety approvals relevant to Durable industrial use.

How is suitability for harsh environments indicated?

The enclosure carries an IP66 ingress rating indicating protection against dust and powerful water jets for exposed installations.
