Chauvin Arnoux F403 Clamp Meter, Max Current 1kA ac, 1.5kA dc CAT IV 600 V

Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CN
Product Details

F403 AC/DC TRMS Clampmeter

The F403 clampmeter is designed for medium-power low-voltage applications in sectors such as LV electricity production and distribution, industry, railways
This clamp multimeter is also suitable for lift/elevator technicians and other lifting and transport specialists
The applications for the clamp multimeter are maintenance, testing, monitoring, diagnostics and connection
Equipped with a fast 12-bit TRMS digital acquisition system
The large backlit display makes it easy to read in all circumstances
Automatic AC/DC detection
Current: 1000 AAC/1500 ADC
AC and DC voltage up to 1000 V
Resistance and audible continuity
TrueInrush current measurement
Min and Max analysis
Relative and differential measurements
Temperature
Adapter function
IP54 protection

Specifications
Attribute Value
Absolute Maximum AC Current Measurement 1kA ac
Absolute Maximum DC Current Measurement 1.5kA dc
Absolute Maximum AC Voltage Measurement 1000V ac
Absolute Maximum DC Voltage Measurement 1000V dc
Absolute Maximum Resistance Measurement 99.99kΩ
Model Number F403
Best DC Current Accuracy ±(1% rdg + 3dgts)
Clamp Meter Type Multifunction Clamp
Best AC Current Accuracy ±(1% rdg + 3dgts)
Best AC Voltage Accuracy ±(1% rdg + 3dgts)
Best DC Voltage Accuracy ±(1% rdg + 3dgts)
Battery Life 350 h
Maximum Conductor Size 48mm
Height 41mm
Minimum Operating Temperature -20°C
True RMS Yes
Best Temperature Measurement Accuracy ±1% +3°C
Functions Measured AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Diode, Frequency, In-Rush Current, Resistance, Temperature
Safety Category Level CAT IV
Weight 600g
Dimensions 92 x 272 x 41mm
Resistance Measurement Resolution 100mΩ
Length 272mm
Width 92mm
Jaw Capacity Busbars 48mm
Power Source Battery
Display Type LCD - Backlit
Best Resistance Measurement Accuracy ±1 % + 5 digits
Safety Category CAT III 1000 V, CAT IV 1000 V
Absolute Maximum Temperature Measurement +1000°C
Maximum Operating Temperature +55°C
Safety Category Voltage 1000V
Temperature Measurement Resolution 0.1°C
Battery Type AA
1 In stock for delivery within 5 working day(s) (Global Stock)
Price (ex. GST) Each
$ 804.80
(exc. GST)
$ 885.28
(inc. GST)
units
Per unit
1 +
$804.80
