RS PRO 2 Core Speaker Cable, 1.5 mm² CSA, 2.60 x 5.2mm od, 100m, Black/Red
- RS Stock No.:
- 136-8134
- Distrelec Article No.:
- 303-94-877
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 reel of 100 metres)*
$264.17
(exc. GST)
$290.59
(inc. GST)
FREE delivery for orders over $60.00 ex GST
In Stock
- Plus 51 unit(s) shipping from 01 January 2026
- Plus 2 unit(s) shipping from 13 January 2026
- Plus 6 unit(s) shipping from 28 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 - 4 | $264.17 | $2.642 |
| 5 + | $217.39 | $2.174 |
*price indicative
- RS Stock No.:
- 136-8134
- Distrelec Article No.:
- 303-94-877
- Brand:
- RS PRO
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Audio Cable Type | Speaker Cable | |
| Number of Cores | 2 | |
| Cross Sectional Area | 1.5 mm² | |
| Insulation Material | PVC | |
| Outer Diameter | 2.60 x 5.2mm | |
| Length | 100m | |
| CPR Certification | Eca | |
| Minimum Operating Temperature | -25 (Static) °C, -5 (Dynamic) °C | |
| Maximum Operating Temperature | +70 (Dynamic) °C, +70 (Static) °C | |
| Sheath Colour | Black/Red | |
| Conductor Material | Bare Copper | |
| Cable Shape | Flat | |
| Sheath Material | PVC | |
| Standards Met | RoHS | |
| Size of Strands | 0.2 mm | |
| Core Strands | 48/0.2 mm | |
| Conductor Strand Type | Stranded | |
| Series | FHP | |
| Number of Strands | 48 | |
| Voltage Rating | 900 V | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Audio Cable Type Speaker Cable | ||
Number of Cores 2 | ||
Cross Sectional Area 1.5 mm² | ||
Insulation Material PVC | ||
Outer Diameter 2.60 x 5.2mm | ||
Length 100m | ||
CPR Certification Eca | ||
Minimum Operating Temperature -25 (Static) °C, -5 (Dynamic) °C | ||
Maximum Operating Temperature +70 (Dynamic) °C, +70 (Static) °C | ||
Sheath Colour Black/Red | ||
Conductor Material Bare Copper | ||
Cable Shape Flat | ||
Sheath Material PVC | ||
Standards Met RoHS | ||
Size of Strands 0.2 mm | ||
Core Strands 48/0.2 mm | ||
Conductor Strand Type Stranded | ||
Series FHP | ||
Number of Strands 48 | ||
Voltage Rating 900 V | ||
- COO (Country of Origin):
- CN
RS PRO Loudspeaker Cable - Red/Black
The RS PRO loudspeaker cable is designed for use wiring various sound systems, fixed and mobile installations. Conductors are identified by colour with this multicore speaker cable.
Temperature
The temperature depends where the multicore speaker cable will be used.
- For static use: -25°C up to +70°C
- For mobile use: -25°C up to +70°C
This unique speaker cable complies with a Directive 2002/95/EC (RoHS), therefore you can be confident when considering a purchase.
The minimum bending radius will vary with different cable designs. The minimum radius to which the multicore speaker cable may safely be bent during your in installation is 8 x Ø.
For this competitive price you will get 100 m to support your project.
The minimum bending radius will vary with different cable designs. The minimum radius to which the multicore speaker cable may safely be bent during your in installation is 8 x Ø.
For this competitive price you will get 100 m to support your project.
