MEAN WELL Switching Power Supply, MPM-30-5, 5V dc, 6A, 30W, 1 Output, 80 → 264V ac Input Voltage
- RS Stock No.:
- 174-8069
- Mfr. Part No.:
- MPM-30-5
- Brand:
- MEAN WELL
18 In Global stock for delivery within 10 working day(s)
Added
Price (ex. GST) Each
$32.99
(exc. GST)
$36.29
(inc. GST)
| Units | Per unit |
| 1 - 9 | $32.99 |
| 10 - 49 | $32.50 |
| 50 + | $31.79 |
- RS Stock No.:
- 174-8069
- Mfr. Part No.:
- MPM-30-5
- Brand:
- MEAN WELL
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
2.73"x1.53" compact size
Suitable for BF application with appropriate system consideration
No load power consumption<0.075W
Extremely low leakage current
Wide operating temp. Range -40 ∼ +85℃
EMI class B for class Ⅱ configuration
Protections: Short circuit / Overload / Over voltage
No minimum load required
3 years warranty
Applications
Portable medical device
Mobile clinical workstation
Medical computer monitor
Medical examination instrument
Suitable for BF application with appropriate system consideration
No load power consumption<0.075W
Extremely low leakage current
Wide operating temp. Range -40 ∼ +85℃
EMI class B for class Ⅱ configuration
Protections: Short circuit / Overload / Over voltage
No minimum load required
3 years warranty
Applications
Portable medical device
Mobile clinical workstation
Medical computer monitor
Medical examination instrument
AC-DC Single output Medical Encapsulated power supply. Output 5Vdc at 6A, PCB through hole, 2xMOPP
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
|---|---|
| Output Voltage | 5V dc |
| Output Current | 6A |
| Power Rating | 30W |
| Number of Outputs | 1 |
| Input Voltage | 80 → 264V ac |
| Mounting Type | PCB Mount |
| Package Type | Encapsulated |
| Length | 69.5mm |
| Width | 39mm |
| Medical Approved | Yes |
| Depth | 24mm |
| Weight | 102g |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
