- RS Stock No.:
- 179-6693
- Mfr. Part No.:
- CMS-2212B
- Brand:
- Nidec Components
2 In Global stock for delivery within 5 working day(s)
Added
Price (ex. GST) Each (In a Pack of 2)
$5.75
(exc. GST)
$6.33
(inc. GST)
Units | Per unit | Per Pack* |
2 - 12 | $5.75 | $11.50 |
14 - 24 | $5.65 | $11.30 |
26 + | $5.545 | $11.09 |
*price indicative |
- RS Stock No.:
- 179-6693
- Mfr. Part No.:
- CMS-2212B
- Brand:
- Nidec Components
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Excellent Contact stability by twin gold plated contact mechanism
Load life of 30000 cycles
Compatible with automatic mounting
Withstands high soldering temperature
Load life of 30000 cycles
Compatible with automatic mounting
Withstands high soldering temperature
Specifications
Attribute | Value |
---|---|
Contact Configuration | DPDT |
Mounting Type | Surface Mount |
Contact Current Rating | 100 (Non-Switching) mA, 100 (Switching) mA |
Terminal Type | Gull Wing |
Actuator Type | Slide |
Length | 10.8mm |
Width | 5mm |
Depth | 3.5mm |
Dimensions | 10.8 x 5 x 3.5mm |
Contact Resistance | 70mΩ |
Voltage Rating | 50V dc |
Operating Temperature Range | -40 → +85°C |
Minimum Operating Temperature | -40°C |
Actuator Material | Polyamide |
Contact Material | Copper Alloy |
Maximum Operating Temperature | +85°C |
