Phoenix Contact MCVU 1.5/7-GFD-3.81 Series Straight PCB Socket, 7-Contact, 1 Row, 3.81 mm Pitch Screw

View all PCB Sockets
Bulk discount available

Subtotal (1 box of 50 units)*

$648.15

(exc. GST)

$712.95

(inc. GST)

Add to Basket
Select or type quantity
In Stock
  • 50 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Box*
50 - 200$12.963$648.15
250 +$11.666$583.30

*price indicative

RS Stock No.:
882-1158
Mfr. Part No.:
1833072
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Product Type

PCB Socket

Number of Contacts

7

Sub Type

Plug-In

Number of Rows

1

Pitch

3.81mm

Current

12A

Termination Type

Screw

Housing Material

Polyamide

Orientation

Straight

Connector System

Board-to-Board

Voltage

320 V

Series

MCVU 1.5/7-GFD-3.81

Minimum Operating Temperature

-40°C

Contact Material

Tin

Maximum Operating Temperature

100°C

Contact Gender

Male

Contact Plating

Tin

Standards/Approvals

No

COO (Country of Origin):
PL
Direct plug-in block, nominal cross section: 1.5 mm², color: green, nominal current: 8 A, rated voltage (III/2): 160 V, contact surface: Tin, type of contact: Male connector, Number of potentials: 7, Number of rows: 1, Number of positions per row: 7, number of connections: 7, product range: MCVU 1,5/..-GFD, pitch: 3.81 mm, connection method: Screw connection with tension sleeve, mounting: Direct mounting, conductor/PCB connection direction: 0 °, Stecksystem: MINI COMBICON, Locking: Screw locking, type of packaging: packed in cardboard
