LM358ADR2G onsemi, Op Amp, 1MHz 20 kHz, 3 → 32 V, 8-Pin SOIC
- RS Stock No.:
- 162-8887
- Mfr. Part No.:
- LM358ADR2G
- Brand:
- onsemi
5000 In Global stock for delivery within 10 working day(s)
Added
Price (ex. GST) Each (On a Reel of 2500)
$0.188
(exc. GST)
$0.207
(inc. GST)
| Units | Per unit | Per Reel* |
| 2500 - 2500 | $0.188 | $470.00 |
| 5000 - 7500 | $0.183 | $457.50 |
| 10000 + | $0.181 | $452.50 |
| *price indicative | ||
- RS Stock No.:
- 162-8887
- Mfr. Part No.:
- LM358ADR2G
- Brand:
- onsemi
Technical data sheets
Legislation and Compliance
Product Details
LM258, LM358, LM2904, NCV2904, Single Supply, Dual Operational Amplifiers, ON Semiconductor
The ON Semiconductor range of dual operational amplifiers are brilliant. Featuring true differential inputs, they can operate single supply voltages between 3V up to 32V. These op amps have many advantages compared to other single operational amps such as, quiescent currents (one-fifth of those with MC1741). ESD clamps are also fitted onto all the input pins.
The common mode input range includes the negative supply, thereby eliminating the need for biasing components in other applications. The output voltage includes the negative power supply voltage.
The common mode input range includes the negative supply, thereby eliminating the need for biasing components in other applications. The output voltage includes the negative power supply voltage.
Features and Benefits:
• Single supply operation: 3V – 32V
• Common mode range extends to negative supply
• Single and split supply operation
• Low input bias currents
• Internally compensated
• True differential input stage
• ESD clamps on the inputs
• Common mode range extends to negative supply
• Single and split supply operation
• Low input bias currents
• Internally compensated
• True differential input stage
• ESD clamps on the inputs
Applications:
• Integrators
• Comparators
• Voltage clamps
• Current regulators
• Linear voltage regulators
• Comparators
• Voltage clamps
• Current regulators
• Linear voltage regulators
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Operational Amplifiers, ON Semiconductor
Specifications
Attribute | Value |
|---|---|
| Mounting Type | Surface Mount |
| Package Type | SOIC |
| Power Supply Type | Single |
| Number of Channels per Chip | 2 |
| Pin Count | 8 |
| Typical Single Supply Voltage | 3 → 32 V |
| Typical Gain Bandwidth Product | 1MHz |
| Typical Slew Rate | 0.6V/µs |
| Maximum Operating Frequency | 20 kHz |
| Maximum Operating Temperature | +70 °C |
| Minimum Operating Temperature | 0 °C |
| Typical Voltage Gain | 100 dB |
| Rail to Rail | No |
| Length | 5mm |
| Width | 4mm |
| Dimensions | 5 x 4 x 1.5mm |
| Height | 1.5mm |
