BALLUFF Hall Effect Sensor, PNP Output, 10 → 30 V dc, 24V
- RS Stock No.:
- 410-4803
- Mfr. Part No.:
- BMF 305K-PS-C-2-S4-00,5
- Brand:
- BALLUFF
1 In Global stock for delivery within 10 working day(s)
Added
Price (ex. GST) Each
$144.86
(exc. GST)
$159.35
(inc. GST)
| Units | Per unit |
| 1 - 4 | $144.86 |
| 5 - 9 | $142.85 |
| 10 + | $140.97 |
- RS Stock No.:
- 410-4803
- Mfr. Part No.:
- BMF 305K-PS-C-2-S4-00,5
- Brand:
- BALLUFF
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
Starter solenoid switch BMF 305K
Electronic switch
Bounce-free switching, no multiple switch points
M8 and M12 plug connectors
Automotive approved
Protection class IP67
Operating voltage 10 → 30 Vdc
3-cable, PNP, NO
Bounce-free switching, no multiple switch points
M8 and M12 plug connectors
Automotive approved
Protection class IP67
Operating voltage 10 → 30 Vdc
3-cable, PNP, NO
Solenoid switch for pneumatic cylinders. "One for all": These sensors let you identify the piston position of pneumatic cylinders through the cylinder wall. Wear and contact-free. Holding brackets / slot nuts available for all commonly available cylinders. Reduced storage - only 1 sensor for different cylinders.
Specifications
Attribute | Value |
|---|---|
| Output Type | PNP |
| Supply Voltage | 10 → 30 V dc |
| Terminal Type | Wire Lead |
| Maximum DC Voltage | 24V |
| Length | 33.5mm |
| Width | 10.5mm |
| Depth | 6.5mm |
| Dimensions | 33.5 x 10.5 x 6.5 mm |
| IP Rating | IP67 |
| Maximum Operating Temperature | +70°C |
| Short Circuit Overload Protection | Yes |
| Reverse Polarity Protection | Yes |
| Minimum Operating Temperature | -25°C |
| Housing Material | Liquid Crystal Polymer |
