- RS Stock No.:
- 656-1163
- Mfr. Part No.:
- TK-4014-RS
- Brand:
- Gemini
16 In Global stock for delivery within 10 working day(s)
Added
Price (ex. GST) Each
$203.75
(exc. GST)
$224.13
(inc. GST)
Units | Per unit |
1 + | $203.75 |
- RS Stock No.:
- 656-1163
- Mfr. Part No.:
- TK-4014-RS
- Brand:
- Gemini
Technical data sheets
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- GB
Product Details
Tinytag Tinytalk2 Data Loggers
Tinytag Talk 2s are compact, lightweight, economical loggers housed in a 35mm film canister and data is downloaded to a PC. These loggers are ideal for long term monitoring of a wide range of applications including environmental research, fridge monitoring, building condition monitoring, schools, laboratories and universities.
16,000 reading capacity
High accuracy, high resolution readings
2 programmable alarms
3 stop options stop when full, wrap around and stop after N readings
Fast data offload via serial or USB cable to a PC
Use with Tinytag Explorer
User-replaceable battery with up to 2 years life
Low battery monitor
Service pack is available separately to maintain the unit: contains replacement battery, desiccant pack and a service instruction sheet
High accuracy, high resolution readings
2 programmable alarms
3 stop options stop when full, wrap around and stop after N readings
Fast data offload via serial or USB cable to a PC
Use with Tinytag Explorer
User-replaceable battery with up to 2 years life
Low battery monitor
Service pack is available separately to maintain the unit: contains replacement battery, desiccant pack and a service instruction sheet
Supplied with
1/2 AA Lithium battery
Specifications
Attribute | Value |
---|---|
Number of Input Channels | 1 |
Model Number | TK-4014 |
Measurement Parameters | Temperature |
Sensor Type | NTC |
Interface Type | Serial, USB |
Data Logger Type | Temperature |
Maximum Temperature Measurement | +85 °C |
Power Source | Battery |
Best Temperature Measurement Accuracy | ±0.5 °C |
IP Rating | IP54 |
Minimum Operating Temperature | -40°C |
Maximum Operating Temperature | +85°C |
Model Number p | TK-4014 |
Alarm | Yes |
Number of Readings Per Channel | 16000 |
Battery Life | 2 yr |
Includes | Battery |
Temperature Measurement Resolution | 0.05°C |
Battery Type | 1/2 AA |
