MEAN WELL Switching Power Supply, MPM-10-3.3, 3.3V dc, 2.5A, 8.3W, 1 Output, 80 → 264V ac Input Voltage
- RS Stock No.:
- 174-8053
- Mfr. Part No.:
- MPM-10-3.3
- Brand:
- MEAN WELL
2 In Global stock for delivery within 10 working day(s)
Added
Price (ex. GST) Each
$18.97
(exc. GST)
$20.87
(inc. GST)
| Units | Per unit |
| 1 - 9 | $18.97 |
| 10 - 49 | $18.58 |
| 50 + | $18.01 |
- RS Stock No.:
- 174-8053
- Mfr. Part No.:
- MPM-10-3.3
- Brand:
- MEAN WELL
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
1.8"x1" compact size
Suitable for BF application with appropriate system consideration
No load power consumption<0.075W
Extremely low leakage current
Wide operating temp. Range -30 ∼ +85℃
EMI class B for class Ⅱ configuration
Protections:
Short circuit / Overload / Over voltage / Over temperature
No minimum load required
3 years warranty
Suitable for BF application with appropriate system consideration
No load power consumption<0.075W
Extremely low leakage current
Wide operating temp. Range -30 ∼ +85℃
EMI class B for class Ⅱ configuration
Protections:
Short circuit / Overload / Over voltage / Over temperature
No minimum load required
3 years warranty
AC-DC Single output Medical Encapsulated power supply. Output 3.3Vdc at 2.5A, PCB through hole, 2xMOPP
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
|---|---|
| Output Voltage | 3.3V dc |
| Output Current | 2.5A |
| Power Rating | 8.3W |
| Number of Outputs | 1 |
| Input Voltage | 80 → 264V ac |
| Mounting Type | PCB Mount |
| Package Type | Encapsulated |
| Length | 45.7mm |
| Width | 25.4mm |
| Medical Approved | Yes |
| Depth | 21.5mm |
| Minimum Temperature | -30°C |
| Maximum Temperature | +85°C |
| Weight | 35g |
