Microchip, 8bit PIC, PIC16LF Microcontroller, 32MHz, 14 kB Flash, 20-Pin QFN
- RS Stock No.:
- 175-3158
- Mfr. Part No.:
- PIC16LF1619-E/ML
- Brand:
- Microchip
Discontinued product
- RS Stock No.:
- 175-3158
- Mfr. Part No.:
- PIC16LF1619-E/ML
- Brand:
- Microchip
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Microchip | |
| Family Name | PIC16LF | |
| Package Type | QFN | |
| Mounting Type | Surface Mount | |
| Pin Count | 20 | |
| Device Core | PIC | |
| Data Bus Width | 8bit | |
| Program Memory Size | 14 kB | |
| Maximum Frequency | 32MHz | |
| RAM Size | 1024 B | |
| USB Channels | 0 | |
| Number of PWM Units | 1 x 10 bit | |
| Number of SPI Channels | 1 | |
| Number of I2C Channels | 1 | |
| Typical Operating Supply Voltage | 1.8 → 5.5 V | |
| Number of USART Channels | 1 | |
| Number of CAN Channels | 0 | |
| Number of UART Channels | 1 | |
| Program Memory Type | Flash | |
| Number of ADC Units | 1 | |
| Maximum Operating Temperature | +125 °C | |
| Length | 4mm | |
| Minimum Operating Temperature | -40 °C | |
| Maximum Number of Ethernet Channels | 0 | |
| Instruction Set Architecture | RISC | |
| ADCs | 12 x 10 bit | |
| Width | 4mm | |
| Number of Ethernet Channels | 0 | |
| Pulse Width Modulation | 1 (2 x 10 bit) | |
| Number of PCI Channels | 0 | |
| Dimensions | 4 x 4 x 0.95mm | |
| Number of LIN Channels | 1 | |
| Height | 0.95mm | |
