Enerpac Single, Portable Hollow Plunger Hydraulic Cylinders, RCH120, 13t, 8mm stroke
- RS Stock No.:
- 903-3595
- Mfr. Part No.:
- RCH120
- Brand:
- Enerpac
On back order for despatch 24/05/2024, delivery within 10 working days from despatch date.
Added
Price (ex. GST) Each
$992.69
(exc. GST)
$1,091.96
(inc. GST)
| Units | Per unit |
| 1 + | $992.69 |
- RS Stock No.:
- 903-3595
- Mfr. Part No.:
- RCH120
- Brand:
- Enerpac
Technical data sheets
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- CN
Product Details
Hollow
Industrial standard high quality single acting/spring return cylinders manufactured from durable high strength alloy steel with a Baked Enamel finish. The plunger is chrome plated to resist wear and rust. The saddles are hardened which prevents the piston from jamming in the top bearing and heavy-duty return springs enable fast piston retraction. Port connections on all cylinders are 3/8-18 NPT and are fitted with a female high flow coupler. Enerpac cylinders are designed to ANSI B30.1 and have a maximum operating pressure of 700 bar.
Note
Cylinders
Industrial standard high quality single acting/spring return cylinders manufactured from durable high strength alloy steel with a Baked Enamel finish. The plunger is chrome plated to resist wear and rust. The saddles are hardened which prevents the piston from jamming in the top bearing and heavy-duty return springs enable fast piston retraction. Port connections on all cylinders are 3/8-18 NPT and are fitted with a female high flow coupler. Enerpac cylinders are designed to ANSI B30.1 and have a maximum operating pressure of 700 bar.
Specifications
Attribute | Value |
|---|---|
| Stroke | 8mm |
| Capacity | 13t |
| Closed Height | 55mm |
| Single/Double Acting | Single |
| Manufacturer Series | RCH |
| Extended Height | 63mm |
| Cylinder Effective Area | 17.9cm² |
| Oil Capacity | 14cm³ |
| Outside Diameter | 69mm |
| Maximum Operating Pressure | 700bar |
| Weight | 1.5kg |
