TDK-Lambda DRL-10 Switched Mode DIN Rail Power Supply, 85 → 264V ac ac Input, 24V dc dc Output, 420mA Output, 10W
- RS Stock No.:
- 137-0854
- Mfr. Part No.:
- DRL10-24-1
- Brand:
- TDK-Lambda
Stocked by manufacturer – available for delivery 01/05/2024
Added
Price (ex. GST) Each
$41.55
(exc. GST)
$45.71
(inc. GST)
Units | Per unit |
1 + | $41.55 |
- RS Stock No.:
- 137-0854
- Mfr. Part No.:
- DRL10-24-1
- Brand:
- TDK-Lambda
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
TDK-Lambda DIN Rail Power Supply
The TDK-Lambda DRL series of DIN-rail power supply have 420mA output current at 24VDC output voltage. This unit has a class II construction (double insulation) and does not require an earth ground connection. This power supply has a universal single-phase input voltage rating ranging between 85VAC and 264VAC.
Features and Benefits
High efficiency up to 87%
Input to output isolation is 3kVAC
LED status indicator
Low no load consumption
No load power is less than 0.3W to 0.5W
Operating temperature ranges between -20°C and 71°C
Power rating is 10W
Ripple factor and noise is less than 240mV
Series connection
Input to output isolation is 3kVAC
LED status indicator
Low no load consumption
No load power is less than 0.3W to 0.5W
Operating temperature ranges between -20°C and 71°C
Power rating is 10W
Ripple factor and noise is less than 240mV
Series connection
Applications
Building control
Climate controls
Renewable energy
Security and surveillance
Smart homes
Climate controls
Renewable energy
Security and surveillance
Smart homes
Certifications
ATEX certified
CE certified
CISPR22 class B
CSA
EN60950
IECEx certified
UL approved
CE certified
CISPR22 class B
CSA
EN60950
IECEx certified
UL approved
Specifications
Attribute | Value |
---|---|
Type | Switched Mode |
Output Voltage | 24V dc |
Output Current | 420mA |
AC or DC Input Voltage | ac |
AC or DC Output Voltage | dc |
Input Voltage | 85 → 264V ac |
Power Rating | 10W |
Electrical Phase | 1 |
Number of Outputs | 1 |
Height | 91mm |
Width | 18mm |
Depth | 55.6mm |
Series | DRL-10 |
Minimum Temperature | -20°C |
Ripple And Noise | 240mV |
Special Features | High In-Service Lifetime, Low No Load Consumption |
Standards Met | IEC 60068-2-27, IEC 60068-2-6, UL 1310, UL 508, UL 60950-1 |
Maximum Temperature | +71°C |
Load Regulation | 240mV |
Mounting Type | DIN Rail Mount |
