Sensata / Crydom GN Series Solid State Relay, 25 A Load, Panel Mount, 280 V ac Load, 280 V ac Control
- RS Stock No.:
- 171-8293
- Mfr. Part No.:
- 84137011
- Brand:
- Sensata / Crydom
23 In Global stock for delivery within 10 working day(s)
Added
Price (ex. GST) Each
$129.07
(exc. GST)
$141.98
(inc. GST)
| Units | Per unit |
| 1 + | $129.07 |
- RS Stock No.:
- 171-8293
- Mfr. Part No.:
- 84137011
- Brand:
- Sensata / Crydom
Legislation and Compliance
- COO (Country of Origin):
- MX
Product Details
The GN Series offers a group of robust and versatile general-purpose AC and DC Panel Mount relays. These powerful single phase SSRs have superior thermal performance thanks to the use of DBC technology. These new generation solid state relays all feature anti-rotation barriers, flexible control voltage options, LED input status indicator, overvoltage protection (on all AC output relays), and a wide range of power ratings to make your product selection easier.
Current rating 10 and 125 Amps
Output voltage 24-280 VAC and 48-660 VAC
LED Input Status Indicator
Improved SEMS screw and washer
Redesigned housing with anti-rotation barriers
Output voltage 24-280 VAC and 48-660 VAC
LED Input Status Indicator
Improved SEMS screw and washer
Redesigned housing with anti-rotation barriers
Specifications
Attribute | Value |
|---|---|
| Maximum Load Current | 25 A |
| Mounting Type | Panel Mount |
| Maximum Load Voltage | 280 V ac |
| Minimum Load Voltage | 24 V ac |
| Maximum Control Voltage | 280 V ac |
| Minimum Control Voltage | 90 V ac |
| Switching Type | Zero Cross |
| Control Voltage Range | 90 → 280 V ac |
| Minimum Load Current | 50 mA |
| Terminal Type | Screw |
| Relay Type | AC |
| Maximum Turn On Time | 20ms |
| Series | GN |
| Load Voltage Range | 24 → 280V ac |
| Dimensions | 58.8 x 44.5 x 30.9mm |
| Standards Met | CE, EN 60950-1, UL |
| Length | 58.8mm |
| Off State Leakage Current | 0.1 mA |
| Maximum Operating Temperature | +80°C |
| Operating Temperature Range | -40 → +80°C |
| Height | 30.9mm |
| Depth | 44.5mm |
| Minimum Operating Temperature | -40°C |
| Special Features | Current Rating 10 and 125 Amps, Output Voltage 24-280 VAC and 48-660 VAC, LED Input Status Indicator |
| Capacitance | 8pF |
