- RS Stock No.:
- 179-6363
- Mfr. Part No.:
- CRFS-2202W
- Brand:
- Nidec Components
On back order for despatch 07/08/2024, delivery within 5 working days from despatch date.
Added
Price (ex. GST) Each (In a Tray of 50)
$4.996
(exc. GST)
$5.496
(inc. GST)
Units | Per unit | Per Tray* |
50 - 50 | $4.996 | $249.80 |
100 - 150 | $4.886 | $244.30 |
200 + | $4.781 | $239.05 |
*price indicative |
- RS Stock No.:
- 179-6363
- Mfr. Part No.:
- CRFS-2202W
- Brand:
- Nidec Components
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Covering the DC 1 Ghz frequency spectrum
Gold-plated contact provides excellent reliability
Applications
Communication devices
Broadcast equipment
FA equipment
Gold-plated contact provides excellent reliability
Applications
Communication devices
Broadcast equipment
FA equipment
Specifications
Attribute | Value |
---|---|
Contact Configuration | DPDT |
Mounting Type | Through Hole |
Contact Current Rating | 100 (Non-Switching) mA, 100 (Switching) mA |
Terminal Type | PC Pin |
Actuator Type | Slide |
Length | 10mm |
Width | 6mm |
Depth | 13.5mm |
Dimensions | 10 x 6 x 13.5mm |
Contact Resistance | 70mΩ |
Voltage Rating | 50V dc |
Minimum Operating Temperature | -40°C |
Operating Temperature Range | -40 → +85°C |
Contact Material | Copper Alloy |
Maximum Operating Temperature | +85°C |
Actuator Material | Polyamide |
