EPCOS, B84110-A 4A 250 V ac 60Hz, Through Hole EMC Filter, Pin, Single Phase
- RS Stock No.:
- 496-4936
- Mfr. Part No.:
- B84110A0000A040
- Brand:
- EPCOS
3 In Global stock for delivery within 10 working day(s)
Added
Price (ex. GST) Each
$19.82
(exc. GST)
$21.80
(inc. GST)
| Units | Per unit |
| 1 - 41 | $19.82 |
| 42 - 82 | $19.34 |
| 83 + | $19.03 |
- RS Stock No.:
- 496-4936
- Mfr. Part No.:
- B84110A0000A040
- Brand:
- EPCOS
Technical data sheets
Legislation and Compliance
Product Details
B84110-A Series
Two-line filter for single-phase systems
Plastic housing
High attenuation
Applications include: medium-performance SMPSUs, data systems, gambling machines
Plastic housing
High attenuation
Applications include: medium-performance SMPSUs, data systems, gambling machines
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
|---|---|
| Maximum Current Rating | 4A |
| Maximum Voltage Rating | 250 V ac |
| Mounting Type | Through Hole |
| Termination Style | Pin |
| Number of Phases | 1 |
| Series | B84110-A |
| Operating Frequency | 60Hz |
| Length | 56mm |
| Depth | 30mm |
| Height | 23mm |
| Capacitance | 220 nF, 4700 x 2pF |
| Inductance | 2.7 x 2 mH |
| Dimensions | 56 x 30 x 23mm |
| Minimum Operating Temperature | -25°C |
| Leakage Current | 0.369 mA |
| Maximum Operating Temperature | +100°C |
| Standards Met | UL 1283 |
