Electrolube UR5041RP250G Black Oxidation Resistance PUR Potting Compound

  • RS Stock No. 160-8481
  • Mfr. Part No. UR5041RP250G
  • Manufacturer Electrolube
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): GB
Product Details

High Performance Polyurethane

A black polyurethane potting compound with high toughness and tear resistance. Ideally suited for marine and harsh environment situations.

Excellent oxidation resistance
Low moisture sensitivity during cure
Low water absorption and high resistance to sea water
Cure time 36 hours
Useable life 20 minutes
Maximum temp. 125°C
Electrical strength 20kV/mm

Electrolube Polyurethane Resin

The Electrolube 250g black polyurethane resin potting compound has high toughness and tears resistance. It is ideally suited for marine and harsh environment situations.

Features and Benefits

• Excellent oxidation resistance
• Low moisture sensitivity during cure
• Low water absorption and high resistance to sea water
• Properties retained at temperatures down to -60°C
• Cure time of 24 hours
• Shelf life is 12 months
• Hardness 85 Shore A
• Useable life 20 minutes
• Maximum temperature is 125°C
• Electrical strength 20kV/mm
• Operating temperature ranges between -60⁰C and 125⁰C

Certifications

• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007

Potting Compounds: Twin Packs

Specifications
Attribute Value
Product Material PUR
Package Type Pack
Package Size 250 g
Special Properties Oxidation Resistance
Cure Time 24 h
Hardness 85 Shore A
Colour Black
Maximum Operating Temperature +125°C
Minimum Operating Temperature -60°C
Operating Temperature Range -60 → +125 °C
69 In stock for delivery within 1 working day(s)
Price (ex. GST) Each
$ 49.58
(exc. GST)
$ 54.54
(inc. GST)
units
Per unit
1 - 4
$49.58
5 - 9
$48.10
10 +
$47.07
