OSI Optoelectronics, PIN DL-4 Si Photodiode, Through Hole TO-8

Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): US
Product Details

OSI Position Sensing Detectors (PSDs)

This family of position sensing detectors (PSD), from OSI Optoelectronics, utilise duo-lateral technology. They provide a continuous analogue output which offer high position accuracy over the majority of the sensing area. One or two dimensional positions can be measured using this range of PSDs.
Suitable applications for these position sensing detectors (PSDs) include; beam alignment, position sensing, angle measurement, height measurements and motion analysis.

Features:
Super linear
High accuracy
Wide dynamic range
High reliability
Duo lateral structure

Photodiodes, OSI Optoelectronics

Specifications
Attribute Value
Wavelength of Peak Sensitivity 670nm
Package Type TO-8
Mounting Type Through Hole
Number of Pins 3
Diode Material Si
Height 5.59mm
Peak Photo Sensitivity 0.4A/W
Polarity Reverse
Diameter 15.24mm
4 In stock for delivery within 5 working day(s) (Global Stock)
Price (ex. GST) Each (In a Tray of 2)
$ 270.945
(exc. GST)
$ 298.039
(inc. GST)
units
Per unit
Per Tray*
2 +
$270.945
$541.89
*price indicative
