Heatsink Isolation Cap for use with TO 3

Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): DE
Product Details

Insulation covers made from polyamide

The insulation covers consist of polyamide reinforced by glass fibre, and the compensation sockets are made from nickel-plated brass. The push-fit sockets compensate for the varying flange heights of different transistor types.

//media.rs-online.com/t_line/LD189794-02.gif
//media.rs-online.com/t_line/LD189795-02.gif
Specifications
Attribute Value
Accessory Type Insulating Cap
For Use With TO 3
188 In stock for delivery within 5 working day(s) (Global Stock)
Price (ex. GST) Each
$ 2.93
(exc. GST)
$ 3.22
(inc. GST)
units
Per unit
1 - 24
$2.93
25 - 99
$2.87
100 - 249
$2.77
250 - 499
$2.72
500 +
$2.67
