TDK-Lambda DRB120-480 Switch Mode DIN Rail Power Supply, 85 → 264V ac ac Input, 24V dc dc Output, 10A Output,

RS Stock No.:: 183-3537
Mfr. Part No.:: DRB-240-24-1
Brand:: TDK-Lambda

TDK-Lambda DRB120-480 Switch Mode DIN Rail Power Supply, 85 → 264V ac ac Input, 24V dc dc Output, 10A Output,

58 In Global stock for delivery within 10 working day(s)

Added

Price (ex. GST) Each

$182.31

(exc. GST)

$200.54

(inc. GST)

Units	Per unit
1 - 9	$182.31
10 - 49	$177.84
50 +	$171.40

RS Stock No.:: 183-3537
Mfr. Part No.:: DRB-240-24-1
Brand:: TDK-Lambda

Technical data sheets

DRB120-480 Series Datasheet

Legislation and Compliance

Product Details

TDK-Lambda DIN Rail Power Supply

The TDK-Lambda DRB series DIN-rail power supply have 10A output current at 24VDC output voltage. Its most outstanding features are compact size and energy efficiency. This power supply has a universal single-phase input voltage rating ranging between 85VAC and 264VAC with adjustable output voltage. Its high immunity makes it suitable for almost every situation. The adjustable output voltage ranges between 24VDC and 28VDC

Features and Benefits

Curve B, conducted and radiated EMI
Easy system integration
High efficiency up to 93%
LED indicator
Narrow width
Operation temperature ranges between -20°C and 70°C
Power rating is 240W
Prolonged lifetime expectation

Applications

Factory automation
general-purpose industrial applications
Process control
Test and measurement

Certifications

CE certified
CISPR11-B
CSA
EN60950
UL approved

Specifications

Attribute	Value
Type	Switch Mode
Output Voltage	24V dc
Output Current	10A
AC or DC Input Voltage	ac
AC or DC Output Voltage	dc
Input Voltage	85 → 264V ac
Power Rating	240W
Electrical Phase	1
Number of Outputs	1
Height	124mm
Width	41mm
Depth	125mm
Series	DRB120-480
Output Voltage Adjustment Range	24 → 28V
Special Features	Curve B Conducted & Radiated EMI, Easier System Integration, High Efficiency, More Space in Control Equipment, Narrow Width, Saves Energy & Cost
Ripple And Noise	<1%
Efficiency	93%
Minimum Temperature	-25°C
Load Regulation	<1%
Maximum Temperature	+70°C
Standards Met	CE Mark, CISPR11-B, CISPR22-B, EN/UL/CSA62368-1, EN55011-B, EN55032-B, EN61204-3 Class A, IEC/EN/UL/CSA60950-1, IEC/EN62477-1, UL508
Mounting Type	DIN Rail Mount
