3M 4800 2.54mm Pitch Straight 14 Way, Through Hole Stamped Pin Open Frame IC Dip Socket, 1A

  • RS Stock No. 827-3546
  • Mfr. Part No. 4814-3000-CP
  • Manufacturer 3M
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): US
Product Details

3M 4800 Series DIP Sockets

3M 4800 series stamped and formed DIP sockets are a dual leaf PCB socket that offer high compression contacts to provide highly reliable termination.

Side and End Stackable
Polyester Glass Filled Marking Insulation Material

Specifications
Attribute Value
Number of Contacts 14
Mounting Type Through Hole
Pin Type Stamped
Pitch 2.54mm
Row Width 7.62mm
Frame Type Open Frame
Termination Method Solder
Contact Plating Tin over Nickel
Current Rating 1A
Orientation Straight
Length 17.65mm
Width 10.16mm
Depth 5.08mm
Dimensions 17.65 x 10.16 x 5.08mm
Housing Material Glass-Filled PET
Contact Material Phosphor Bronze
Series 4800
Maximum Operating Temperature +85°C
Minimum Operating Temperature -25°C
335 In stock for delivery within 5 working day(s) (Global Stock)
Price (ex. GST) Each
$ 0.78
(exc. GST)
$ 0.86
(inc. GST)
units
Per unit
1 +
$0.78
