Cinch, FD 15 Way Panel Mount D-sub Connector Plug, 2.76mm Pitch

  • RS Stock No. 449-770
  • Mfr. Part No. RS000130000EL1K
  • Manufacturer Cinch
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): GB
Product Details

Cinch Filter D-sub Plug and Socket Connectors with Solder Bucket Terminals

Filter D-Sub plug and socket connectors with solder bucket terminals and turned pin contacts with epoxy encapsulated tubular capacitors individually inserted into them for maxmum resistance to hazardous environments. The rear shell of these filter D connectors is made from electrolytic nickel and the front shell is made from steel with a bright tin finish, in addition, the filtered d-sub plug connectors have grounding indents on the front shell for EMI/RFI shielding. These filter D subminiature plug and socket connectors have a capacitance of 1000 pF and 3.05mm diameter mounting holes.

Standards

Meets relevant dimensional requirements of CECC-73301-802; MIL-C-24308; DIN-14652; BS-9523; F0013; BT-217; HE-501

//media.rs-online.com/t_line/L449764-01.gif

Standards

CECC-73301-802; MIL-C-24308; DIN-41652; BS-9523; F0013; BT-217; HE-501

Cinch Filtered 'D' Connectors

Solder termination connection
Designed to limit cable borne EMI via a 1000pF capacitor from each contact to ground
Enhances rejection levels in VHF & UHF bands
Bright tin finish on steel backshells shields against RFI/EM and the potted construction allows use in hazardous environments
Gold plated turned pin contacts
High quality machined contact
Flammability rating: UL94V-0
Suitable for military, industrial or commercial applications and computer interfacing etc

Specifications
Attribute Value
Number of Contacts 15
Gender Male
Body Orientation Straight
Mounting Type Panel Mount
Pitch 2.76mm
D Connector Type Filtered D-Sub
Termination Method Solder
D-Sub Shell Size A
Current Rating 5.0A
Housing Material Steel
Voltage Rating 200 V ac/dc
Length 39.14mm
Width 10.2mm
Depth 12.55mm
Dimensions 39.14 x 10.2 x 12.55mm
Minimum Operating Temperature -25.0°C
Series FD
Contact Material Copper Alloy
Maximum Operating Temperature +125°C
