Radiall, jack Flange Mount SMA Connector, 50Ω, Solder Termination, Straight Body
- RS Stock No.:
- 170-2464
- Mfr. Part No.:
- R125454000
- Brand:
- Radiall
On back order for despatch 06/08/2024, delivery within 10 working days from despatch date.
Added
Price (ex. GST) Each (In a Box of 100)
$24.483
(exc. GST)
$26.931
(inc. GST)
| Units | Per unit | Per Box* |
| 100 - 100 | $24.483 | $2,448.30 |
| 200 - 300 | $23.871 | $2,387.10 |
| 400 + | $23.504 | $2,350.40 |
| *price indicative | ||
- RS Stock No.:
- 170-2464
- Mfr. Part No.:
- R125454000
- Brand:
- Radiall
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- IN
Product Details
Female SMA socket with stub flange
Female SMA socket with stub flange.
These sockets are designed to be panel-mounted using four mounting holes (screws not provided).
Solder connection.
These connectors are high performance and may be used for all high frequency applications.
These sockets are designed to be panel-mounted using four mounting holes (screws not provided).
Solder connection.
These connectors are high performance and may be used for all high frequency applications.
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Radiall SMA Gold Plated Stainless Steel
SMA connectors to MIL-C-39012 and BS 9210 N006 standards for high performance RF applications. Connectors have gold plated stainless steel bodies in a variety of popular semi-rigid and flexible cable applications.
Specifications
Attribute | Value |
|---|---|
| Coaxial Connector Type | SMA Connector |
| Gender | Female |
| Mounting Type | Flange Mount |
| Impedance | 50Ω |
| Termination Method | Solder |
| Body Orientation | Straight |
| Bulkhead | No |
| Operating Frequency | 0 to 18GHz |
| Minimum Operating Temperature | -65°C |
| Body Plating | Gold |
| Maximum Operating Temperature | +165°C |
| Contact Material | Beryllium Copper |
| Contact Plating | Gold over Nickel |
